S402 Load Cell

The S402 Stainless Steel Load Cell is a high quality, robust single point sensor available in four standard ranges, measuring forces from 100 N to 1000 N. A 5,000 Ω Wheatstone bridge and thin-film strain gauge provide extremely low power consumption and unmatched long term stability. If your range requirements are different, contact us and we will work to meet the desired parameters.

Ask Questions / Get Quote

Features:	Applications:
· Stainless steel · Compact, low profile design · Long-term stability · Low power consumption · Low hysteresis	· Orthopedic instruments · Press tool · Printing · Process control · Hydraulics force control

Download Datasheet Load Cell Handling Application Note

Capacity	25, 50, 100, 200, 500, 1000, 2000N
Hysteresis	+/- 0.03% FSO
Non-Repeatability	+/- 0.01% FSO

S400 – S401 – S402 – S420 Application Notes

The S400, S401, S402, & S420 Load Cells are a family of stainless steel-bodied assemblies containing a monolithic sensing element with a strain gage applied, capable of producing a linear, analog voltage output in response to loadings of 0‐50 lbs up to 1000 lbs
